D-Link 16-Port Gigabit Unmanaged Desktop Switch (DGS-1016D)

Brand

Dlink

Part number

DGS-1016D/B

EAN

790069269981

Management features

Switch type

Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

16

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Network

Full duplex

Yes

Data transmission

Switching capacity

32 Gbit/s

MAC address table

8000 entries

Store-and-forward

Yes

Maximum data transfer rate

1 Gbit/s

Packet buffer memory

0.340 MB

Design

Number of fans

0 fan(s)

Safety

CSA + NRTL/C

Power

Power source

100-240VAC, 50/60 Hz

Power supply included

Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)

No

Other features

Dimensions (WxDxH)

280 x 180 x 44 mm

I/O ports

10BASE-T, 100BASE-TX & 1000BASE-T

Operational conditions

Operating temperature (T-T)

-10 - 55 °C

Storage temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95%

Weight & dimensions

Weight

1.75 kg

Packaging data

Package width

180 mm

Package depth

328 mm

Package height

108 mm

Package weight

1.77 kg

Technical details

Shipping (inner) case height

35.9 cm

Shipping (inner) case width

19.7 cm

Shipping (inner) case length

57.2 cm

Shipping (inner) case net weight

8.84 kg

Products per shipping (inner) case

5 pc(s)

Pallet gross weight (air)

304.5 kg

Master (outer) cases per pallet (air)

30 pc(s)

Products per pallet (air)

150 pc(s)

Pallet gross length

110 cm

Pallet gross width

120 cm

Pallet height (air)

121.2 cm

Pallet gross weight (sea)

495 kg

Master (outer) cases per pallet (sea)

50 pc(s)

Products per pallet (sea)

250 pc(s)

Pallet height (sea)

193 cm

Shipping (inner) case gross weight

9.5 kg

Logistics data

Harmonized System (HS) code

85176990
